Items

Specification

Working Voltage

　3 Phase 50Hz 380V (Adjustable at request)

Motor Power

4+2.2KW

Compressed Air

　0.7Mpa

Hydraulic System Working Pressure

13Mpa（Max）

Hydraulic Station Cooling Style

Fan Cooling

Hydraulic Platen Diameter

　￠570mm

Conveying Pipe Diameter

　￠76mm

Packing Container

Small Bucket/Pail/Tin/Can

Filling Quantity

100-400ml, 300-800ml,800-1500ml

Filling Speed

10-35pcs/minute

Filling Tolerance

+/-2g

Filling Style

　Automatic

Filling Quantity Control

　Automatic（Hydraulic Volumetric Dosing Cylinder）

Material Drum

　200L Straight Drum

Applicable Material

　Putty, Acrylic Sealant, Soap, other Paste Materials

Structure

Hydraulic Drum Press + Filling Station

Packing Size

Hydraulic Drum Press: 321*85*124cm

  Filling Station: 115*113*180cm

Gross Weight

　Hydraulic Drum Press: 1140Kgs

  Filling Station: 405Kgs
