| Product Name:Manual Cartridge Filling Machine with 4 Filling Heads |
|
|
|
|
Description： |
|
|
|
|
Items
|
Specification
|
|
Working Voltage
|
3 Phase 50Hz 380V & 1 Phase 50Hz 220V
|
|
Motor Power
|
4KW
|
|
Compressed Air
|
0.7Mpa
|
|
Hydraulic System Pressure
|
13Mpa（Max）
|
|
Hydraulic Station Cooling Method
|
Fan Cooling
|
|
Plate Diameter
|
￠570mm
|
|
Conveying Pipe Diameter
|
￠76mm
|
|
Packing Container
|
300ml Cartridge
|
|
Filling Volume
|
160～320ml
|
|
Filling Speed
|
20-35pcs/minute
|
|
Filling Tolerance
|
+/-5g
|
|
Filling Style
|
Manual
|
|
Sealing Style
|
Manual
|
|
Quantity Control
|
Automatic （Stroke Length）
|
|
Material Container
|
200L Straight Drum
|
|
Applicable Material
|
Silicone Sealant, Acrylic Sealant, PU Sealant, MS Sealant, Construction Adhesive (Liquid Nails)
|
|
Structure
|
Hydraulic Drum Press+Filling and Sealing Station
|
|
Packing Size
|
Hydraulic Drum Press: 321*85*124cm
Filling and Sealing Station: 160x83x133cm
|
|
Gross Weight
|
Hydraulic Drum Press: 1140Kgs
Filling and Sealing Station: 200Kgs
|
|
|
|
|
Manual Cartridge Filling Machine
